Starway Vehicle

Special Semi trailer

4 axles 45cbm fuel tanker semi trailer

The Starway fuel tanker trailer is all about safety and efficiency, making it a great choice for transporting multiple types of liquid products. The tank body, made from aluminum alloy, can be customized into an oval or square shape and is divided into compartments, allowing it to carry up to six different oil products at the same time. If you need to transport liquids that need temperature control, Starway also offers a heat-preservation option to keep things stable during the journey.

Safety is a top priority with this tanker. Inside the tank, anti-wave dividers reduce liquid movement, keeping the center of gravity stable and making the ride smoother and safer. Each tank also goes through high-pressure gas leakage testing to ensure it’s strong, reliable, and leak-proof.

For added flexibility, the Starway tanker can be fitted with different pumps, like centrifugal or gear pumps, which offer high flow and quick suction for faster loading and unloading. The trailer also comes with advanced features like flow meters, retractable coils with refueling guns, and even tax-controlled refueling machines, making it a complete and reliable solution for transporting liquids safely and efficiently.

The advantage of starway 4 axles 45CBM Carbon Steel tanker trailer

  • Customizable Tank Design: The aluminum alloy tank can be made into an oval or square shape and customized with multiple compartments to carry up to six different oil products at once.
  • Heat-Preservation Option: An optional heat-preservation feature ensures liquids remain at a stable temperature during transport, perfect for temperature-sensitive products.
  • Enhanced Safety Features: Anti-wave dividers inside the tank minimize liquid movement, providing better stability and reducing the risk of tipping during transit.
  • Leak-Proof Assurance: Every tank undergoes high-pressure gas leakage testing to guarantee strength, reliability, and a leak-proof design.

Technical Specifications :

Dimension (L*W*H) : 13000*2500*3800mm
Material : Carbon Steel /Aluminum Steel /Stainless Steel
Apply : Fuel,oil etc Liquid Cargo Transporting Apply
Tire : 11.00R20,12R22.5,12.00R20,385/65R22.5 Trangle/Hankook/Brigestone brand
Axles : 13T/16/20/25 to BPW or Starway ,FUWA Brand
Tank Thickness : 5mm
Dish End Thickness : 6mm
Buffle Thickness : 4mm
Compartment : 1 to 9 (Customer Requirement )
Manhole : 3 sets,Aluminum,Anti-Explosion
Discharge Valve : 2-3 inch
Bottom Valve : 4 inch Aluminum
Discharge Pipe : 3 inch rubber hose,6mm/each
Hose Carrier : 2 pcs Carbon Steel/Aluminum
Kingpin : 2 inch or 3.5 inch JOST Brand
Brake system : Wabcoe Valve with air chamber
Landing Gears : Jost brand two-speed Manual operating heavy duty 28 ton
Suapension : Starway vehicle Bogie suspension,spring suspension,Air suspension
Extinguisher : 3mm,4mm,6mm diamond steel plate
Other parts : 2 tool boxes 2 spare tire carrier
Functions : Transport container,loose cargo,bulk cement,bulk rice,etc
Vehicle painting :KTL Electrophoresis painting and power spraying
(The specifications shown are for reference only. We’re able to manufacture carbon steel fuel tank oil trailers in any configuration you need.)
